Bobcat S185 Skid Steer / CTL
Bobcat S185
Average price
$22,900
5+
sold in last year
General overview
Produced from 2003 to 2008, the Bobcat S185 is a skid steer loader for construction work involving material handling and loading in confined areas. The Bobcat S185 pairs 45 kW (61 hp) of engine power with a rated operating capacity of 839 kg (1,850 lb) and an operating weight of 2,821 kg (6,220 lb).
It uses a fully hydrostatic transmission with 4WD and infinitely variable hydrostatic speeds, with optional 2-speed (low/high) operation and a maximum speed of 17 km/h (10.6 mph). Dump height is 2,311 mm (7 ft 7 in), and loader hydraulics are listed at 64 L/min (16.9 gpm) with system pressure at couplers of 227.5 bar (3,300 psi).
Year
2003, 2004, 2005, 2006, 2007, 2008
Country of manufacturing
United States
General specifications
Dimensions
Length
Height
Width
mm
~ in
mm
~ in
mm
~ in
Engine Power
61 hp
Operating Weight
2,821 kg
Rated Operating Capacity
839 kg
Dump Height
2,311 mm
Max. speed
17 km/h
Additional specifications
Emission standard level
US EPA/CARB interim Tier 4 / EU Stage IIIA (V2,607); US EPA/CARB Tier 2 / EU Stage II (V2,003)
Displacement
2 cu(m)
Speeds
Infinitely variable hydrostatic; optional 2-speed (low/high)
Fuel tank
90 L
Number of batteries
1
Wheelbase
1,031 mm
Axles
4WD
Battery Voltage
12
Final drive
Prestressed #80 HSOC endless roller chain and sprockets in sealed chaincase (two chains per side)
Net Power (ISO 9249)
58 hp
Manufacturer and Model
Kubota V2,607-DI-T-E3B (also available: Kubota V2,003-M-DI-T-E2B)
Alternator Rating
90
Pump flow loader
64 L/min
2 Speed High
17 km/h
Brakes
Two independent hydrostatic systems; secondary brake: one hydrostatic transmission; parking brake: mechanical disc
System Pressure at Couplers
22,752 kPa
Hydraulic Horsepower Flow
24 hp
Length Without Bucket
2,585 mm
Length With Foundry Bucket
3,309 mm
Width Without Bucket
1,676 mm
Height to Top of ROPS
1,938 mm
Height to Hinge Pin
3,002 mm
Dump Height With Foundry Bucket
2,311 mm
Dump Reach With Foundry Bucket
751 mm
Ground Clearance
190 mm
Angle of Departure
23 deg
Front Turn Radius With Foundry Bucket
2,001 mm
Dump Angle (full lift height)
42 deg
Bucket Rollback (ground level)
25 deg
Tipping Load
1,848 kg
SAE Rated Operating Capacity With Counterweight
885 kg
Boom Breakout Force With Foundry Bucket
15 kg
Bucket Breakout Force With Foundry Bucket
15 kg
Powertrain Type
Fully hydrostatic transmission, 4WD
Operating Weight - Rear
2,821 kg
Standard features
10-16.5 8PR
Seed spacing
11 mm
Cylinders
4
Bobcat S185 Skid Steer / CTL Listings
$21,900
61 hp
17 km/h
Kubota V2607-DI-T-E3B (also available: Kubota V2003-M-DI-T-E2B)
1714 hours
Havana, United States
Compare Bobcat S185 Skid Steer / CTL to other skid steer / ctl
Not sure which equipment to choose? Use our comparison tool to easily compare equipment side by side based on key features.
Add model
Add model
No reviews yet
Be the first to review this model.
Leave a review. Get a promo code
Leave a review and receive a promo code for your next purchase.
No questions yet
Be the first to ask a question about this model and help other buyers learn more.
Heavy equipment insights from JumboBee
Got Questions?
Our FAQ section covers everything from shipping and listing to buying with confidence.
Can't find what you're looking for?
Sign up and talk to an expert.
Most popular
What is the average price of a Bobcat S185?
No confirmed market price is supplied for the Bobcat S185. Check current listings and compare the machine’s condition, location, and configuration.
What are the key advantages of the Bobcat S185?
Key listed capabilities include 45.5 kW (61 hp) engine power, a rated operating capacity of 839 kg (1,850 lb), fully hydrostatic 4WD, and a 90 L (23.8 US gal) fuel tank. Optional 2-speed travel reaches 17 km/h (10.6 mph).
What type of engine does the S185 use?
The S185 is listed with a Kubota V2607-DI-T-E3B engine. A Kubota V2003-M-DI-T-E2B is also available.
How much horsepower does the S185 have?
The S185 has 45.5 kW (61 hp) engine power. Its Net Power (ISO 9249) is listed as 43.3 kW (58 hp).
What fuel does the Bobcat S185 use?
The supplied specifications do not confirm the fuel type for the Bobcat S185. They list a 90 L (23.8 US gal) fuel tank.
What jobs is this Skid Steer Loaders best suited for?
Its listed capacity, dump height, and hydrostatic 4WD make it suitable for general loading and material-handling work. Verify the bucket, attachments, site conditions, and required lift capacity for the intended job.
What is the expected lifespan of the S185?
The supplied data does not provide an expected service-life estimate for the S185. Actual lifespan depends on maintenance, operating conditions, hours of use, and the condition of the engine, hydraulics, drivetrain, and structure.
What should a buyer check when purchasing a used Skid Steer Loaders?
Inspect the engine, hydraulic hoses and couplers, loader arms, bucket, tires, chaincase, brakes, and ROPS. Check for leaks, unusual noise, wear, and evidence of neglected maintenance. Test lift, steering, travel, and all installed attachments before purchase.
