Bobcat E35 Compact & Mini (Tracked) Excavators
Bobcat E35
5+
sold in last yearGeneral overview
The Bobcat E35 is an excavator built for digging, trenching, and material handling on construction sites and similar earthmoving jobs. It is powered by an 18 kW (24 hp) engine and has an operating weight of 3,474 kg (7,660 lb), giving it a defined size and power class for general excavation work.
Key operating specifications include a maximum digging depth of 3,078 mm (10 ft 1 in), maximum reach at ground level of 5,189 mm (17 ft), and maximum cutting height and maximum loading height of 3,485 mm (11 ft 5 in). Hydraulic performance is listed at 63 L/min (16.6 gpm) maximum rated flow with 205.9 bar (2,990 psi) system relief pressure, while bucket digging force is 32 kN (7,190 lbf) and stick digging force is 20 kN (4,500 lbf).
Year
2021
Country of manufacturing
United States
General specifications
Dimensions
Length
Height
Width
4,826 mm
~190 in
2,443 mm
~96.2 in
1,769 mm
~69.6 in
Engine Power
24 hp
Fuel tank
51 L
Width
1,769 mm
Operating Weight
3,474 kg
Maximum Rated Flow
63 L/min
System Relief Pressure
20,594 kPa
Maximum Travel Speed - Low
2 km/h
Maximum Travel Speed - High
4 km/h
Shipping Height - Top of Cab
2,443 mm
Maximum Digging Depth
3,078 mm
Maximum Reach at Ground Level
5,189 mm
Maximum Cutting Height
3,485 mm
Maximum Loading Height
3,485 mm
Bucket Digging Force - ISO
32 kN
Stick Digging Force - ISO
20 kN
Additional specifications
Rated power
18.5 kW
Reference Bucket Capacity
0.1 cu(m)
Additional Options
Long-arm option; Extendable arm option; Angle blade; Optional air conditioning and cab enclosure.
Bobcat E35 Compact & Mini (Tracked) Excavators Listings
Looking for Bobcat E35 Compact & Mini (Tracked) Excavators?
See similar listingsCompare Bobcat E35 Compact & Mini (Tracked) Excavator to other compact & mini (tracked) excavators
Not sure which equipment to choose? Use our comparison tool to easily compare equipment side by side based on key features.
Bobcat E35 Compact & Mini (Tracked) Excavator
24 hp
4826 mm × 1769 mm × 2443 mm
Add model
Add model
No reviews yet
Be the first to review this model.
Leave a review. Get a promo code
Leave a review and receive a promo code for your next purchase.
No questions yet
Be the first to ask a question about this model and help other buyers learn more.
Heavy equipment insights from JumboBee
Got Questions?
Our FAQ section covers everything from shipping and listing to buying with confidence.
Can't find what you're looking for?
Sign up and talk to an expert.
Most popular
What is the average price of a Bobcat E35?
No confirmed market price is supplied for the Bobcat E35. Check current listings and compare machine condition, location, and configuration.
What are the key advantages of the Bobcat E35?
The supplied specifications list a 17.9 kW (24 hp) engine, 3,078 mm (121.2 in) maximum digging depth, and 5,189 mm (204.3 in) maximum reach at ground level. Available options include long-arm and extendable-arm configurations, an angle blade, and optional air conditioning and cab enclosure.
What type of engine does the E35 use?
The supplied data confirms engine power of 17.9 kW (24 hp), but it does not specify the engine type or engine model.
How much horsepower does the E35 have?
The Bobcat E35 has 17.9 kW (24 hp) of engine power.
What fuel does the Bobcat E35 use?
The supplied data lists a 51 L (13.5 US gal) fuel tank, but it does not confirm the fuel type.
What jobs is this Excavators best suited for?
The supplied specifications indicate excavation capability with a 3,078 mm (121.2 in) maximum digging depth, 5,189 mm (204.3 in) ground-level reach, and 3,485 mm (137.2 in) maximum loading height. Suitability for a specific job depends on site conditions, attachments, and required configuration.
What is the expected lifespan of the E35?
The supplied data does not provide an expected service life for the Bobcat E35. Assess maintenance records, operating condition, hydraulic performance, undercarriage wear, and signs of leaks when evaluating a machine.
What should a buyer check when purchasing a used Excavators?
Check maintenance records, engine operation, hydraulic functions, leaks, undercarriage wear, attachment condition, cab and controls, and overall structural condition. Confirm the installed configuration and options, such as the arm type, angle blade, air conditioning, or cab enclosure.
